Chipset
Intel Small Form Factor (ULV) Montevina Chipset
Video Card
Intel Integrated Graphics Media Accelerator 4500MHD
Display
12.1" Premium WXGA (1280x800) LED Display (Wide View)
12.1" Premium WXGA (1280x800) Daylight Viewable LED Display (Wide View)
12.1" Premium WXGA (1280x800) Daylight Viewable LED Display (Wide View)
Optical Drive
8X DVD-ROM, 24X CDRW/DVD, 8X DVD+/-RW (external media bay)
Connectivity
Wireless LAN:
Dell Wireless 1397(802.11g)
Dell Wireless 1510 (802.11 a/g/n 2x2)
Intel WiFi Link 5100 (802.11a/g/n 1x2)
Intel WiFi Link 5300 (802.11a/g/n 3x3)
Mobile Broadband:
Dell Wireless 5720 EV-DOrA Mobile Broadband Minicard
Dell Wireless 5530 HSUPA/HSDPA Mobile Broadband Minicard
Dell 365 Bluetooth Module
Gigabit Ethernet (10/100/1000)
Dell Wireless 1397(802.11g)
Dell Wireless 1510 (802.11 a/g/n 2x2)
Intel WiFi Link 5100 (802.11a/g/n 1x2)
Intel WiFi Link 5300 (802.11a/g/n 3x3)
Mobile Broadband:
Dell Wireless 5720 EV-DOrA Mobile Broadband Minicard
Dell Wireless 5530 HSUPA/HSDPA Mobile Broadband Minicard
Dell 365 Bluetooth Module
Gigabit Ethernet (10/100/1000)
Security
Trend Micro Worry-Free Business Security Services (up to 3 year subscription)
Optional Smart Card Reader (via Express Card slot)
TPM 1.2
Finger Printer reader option
Dell ControlVault
Dell ControlPoint Security Manager
Optional Smart Card Reader (via Express Card slot)
TPM 1.2
Finger Printer reader option
Dell ControlVault
Dell ControlPoint Security Manager
Multimedia
1 speaker, digital microphone
Ports, Slots & Chassis
Ports:
1394, USB 2.0 (x2, one powered), USB 2.0/eSATA, VGA, RJ-45, Audio
Slots:
54mm Expresscard / SD Card slot
Preliminary Weight (Starting):
3.62lbs (1.64 kg) with 4-cell battery
3.78lbs (1.72 kg) with 6-cell battery
Preliminary Dimensions:
11.7" x 8.7" x 1.1" (297x220.6x27.4mm)
With WWAN: 11.7" x 8.8" x 1.1" (297x222.6x27.4mm)
Multi-touch – Finger / Capacity Touch Screen
Pen - EM Digitizer
Eraser functionality actuated via side switch
Optional tether
Interaction with display controlled by three different replaceable "tips" for user-selectable writing experiences
Full - size keyboard
Dual - pointing; rubber domes with leveling rods
Scroll Wheel with enter and back functionality (on display/slate)
Docking:
XT2 Media Slice
Media Bay:
E-family modular (external) media bay: 8X DVD-ROM, 24X CDRW/DVD, 8X DVD+/-RW, Second Hard Drive
1394, USB 2.0 (x2, one powered), USB 2.0/eSATA, VGA, RJ-45, Audio
Slots:
54mm Expresscard / SD Card slot
Preliminary Weight (Starting):
3.62lbs (1.64 kg) with 4-cell battery
3.78lbs (1.72 kg) with 6-cell battery
Preliminary Dimensions:
11.7" x 8.7" x 1.1" (297x220.6x27.4mm)
With WWAN: 11.7" x 8.8" x 1.1" (297x222.6x27.4mm)
Multi-touch – Finger / Capacity Touch Screen
Pen - EM Digitizer
Eraser functionality actuated via side switch
Optional tether
Interaction with display controlled by three different replaceable "tips" for user-selectable writing experiences
Full - size keyboard
Dual - pointing; rubber domes with leveling rods
Scroll Wheel with enter and back functionality (on display/slate)
Docking:
XT2 Media Slice
Media Bay:
E-family modular (external) media bay: 8X DVD-ROM, 24X CDRW/DVD, 8X DVD+/-RW, Second Hard Drive
Power
4-cell 28W/Hr Li-Ion primary
6-cell 42W/Hr Li-Ion primary
45W/Hr Li-Ion 9-cell High Capacity Battery Slice
45W (Small form factor), 65W, 90W, Combo Auto/Air
6-cell 42W/Hr Li-Ion primary
45W/Hr Li-Ion 9-cell High Capacity Battery Slice
45W (Small form factor), 65W, 90W, Combo Auto/Air
Regulatory
Regulatory Model: PP12S
Product Safety, EMC and Environmental Datasheets
Dell Regulatory Compliance Home Page
Dell and the Environment
Product Safety, EMC and Environmental Datasheets
Dell Regulatory Compliance Home Page
Dell and the Environment
